Features

Up to 1.25 Gbps bi-directional communication

10/100/1000 Mbps Auto-Negotiation

Complies with SFP Multi-Source Agreements standards (MSA)

RJ45 Ethernet connector

Fully Hot Pluggable

Auto crossover (MDI / MDI-X) detection

Compatible with Cisco equipment

Technical Specifications

Warranty 3 Years

Industry Standards IEEE 802.3 10BASE-T

Industry Standards IEEE 802.3ab 1000BASE-T

Industry Standards IEEE 802.3u 100BASE-TX

Local Unit Connectors 1 - RJ-45 Female

Maximum Data Transfer Rate 1.25 Gbps

Max Transfer Distance 100 m (328 ft)

DDM No

Compatible Networks 10/100/1000 Mbps

Auto MDIX Yes

Product Length 2.8 in [70 mm]

Product Width 0.5 in [13 mm]

Product Height 0.5 in [13 mm]

Product Weight 0.7 oz [21 g]

Operating Temperature 0°C to 70°C (32°F to 158°F)

Storage Temperature -40°C to 85°C (-40°F to 85°F)

Humidity 30~70% RH

Shipping (Package) Weight 0.1 lb [0.1 kg]

Included in Package 1 - 10/100/1000 Mbps RJ45 SFP

www.startech.com

1 800 265 1844
