StarTech.com IPUSB2VGA Manual de Instruções

Manual Revision: 04/09/2013For the most up-to-date information, please visit: www.startech.comDE: Bedienungsanleitung - de.startech.comFR: Guide de l&

Instruction Manual7Installation for Mac OS X1. Insert the Driver CD (included) into the CD/DVD-ROM drive.2. Browse through the Driver CD and locate

Instruction Manual8CongurationWindows 2000/XP/Vista/7To congure the image being displayed by the monitor that is connected to the VGA Video Adapter,

Instruction Manual9Congure the secondary display by selecting it from the “Display” drop-down menu, then adjusting the desired settings:Using the Sec

Instruction Manual10Similarly, the screen resolution, color quality, position of the screen and rotation of the screen can be adjusted from this menu.

Instruction Manual11Mac OS XTo congure the display settings and monitor positions, bring up the Displays Preferences from the System Preferences menu

Instruction Manual12To use both extended and mirrored displays simultaneously, turn o mirroring then in the “Arrangement” page press and hold the ‘cm

Instruction Manual13SpecicationsBus InterfaceUSB 2.0TCP/IPVideo Signal VGA (RGBHV)Connectors1 x DE-15 VGA female1 x USB mini-B female2 x 3.5mm mini-j

Instruction Manual14Technical SupportStarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-l

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.StarTech.com is your one-stop source for every connectivity part yo

Instruction ManualFCC Compliance StatementThis equipment has been tested and found to comply with the limits for a Class B digital dev

Instruction ManualiTable of ContentsIntroduction ...1Packagin

Instruction Manual1IntroductionThe StarTech.com IPUSB2VGA Video Adapter oers versatile performance by providing either a USB-to-VGA connection or an

Instruction Manual2Power ConnectorRJ45 LAN connector3.5mm mini-jack MIC input3.5mm mini-jack Speaker outputDE-15 VGA connector (output)USB Hub connect

Instruction Manual3Installation Diagram

Instruction Manual4InstallationNOTE: The following installation steps must be completed prior to connecting USB adapter to the host computer, to ensur

Instruction Manual5Hardware Installation for USB1. Connect the VGA display device to the Video Adapter and power on the Display Device. If using the

Instruction Manual64. If a DHCP server is available, the VGA Video Adapter will automatically obtain the IP address and network settings to be able t
